Electric hydraulic tilt tables
E-mail: sale@gidrolast.com
International sales team
Technical specifications
| Capacity:from 1000 to 2000 kg; |
| Platform lenght:from 800 to 1800 mm; |
| Platform width:from 1300 to 2000 mm; |
| Minimum height:300 mm; |
| Capsizing angle:90°; |
| Sense of tilting:one way; |
| Mains supply:three-phase 380w, 50Hz; |
| Lift speed with/without load:30 mm/s; |
| Lowering speed with/without load:25 mm/s; |
| Lift cycles max:10 per hour; |
| Lift function:electro-hydraulic; |
| Delivery:fully assembled; |
| Net weight:190 kg. |
Product details
- A. Remote hydraulic station (4 kWhkW).
- B. Remote control panel (1pc).
- C. Remote wired control panel (yes).
- D. Corrugated coating (yes).
- E. Limit switches for limiting the lifting height and shutting (yes).
- F. Inspection service hatch (yes).
- G. Reinforced lifting platform (yes).
- H. Press – oilers (greases) for service maintenance of all mobile units of the lifting mechanism (yes).
- K. Overload protection.
